Owner: NY Mets
Location: 123-01 Roosevelt Avenue Flushing , NY
Client: NY Mets
Year round electrical infrastructure maintenance of Citifield Stadium including operation & maintenance of the lighting & controls systems, audio visual systems, tv & cable network broadcast systems, and also the operation of computerized scoring system during the baseball season.
Owner: S.L. Green Properties
Location: 51 East 42nd Street New York , NY
Client: S.L. Green
Electrical Maintenance of S.L. Green’s entire office building at 51 East 42nd Street in Manhattan.
Location: 111 8th Avenue & 75 9th Avenue New York , NY
Electrical Maintenance at two of Google’s New York Offices consisting of over one million square feet. Maintenance includes all the electrical systems and telecommunications.
Owner: United Nations
Location: 42nd Street & 1st Avenue New York , NY
Client: United Nations
UNITED NATIONS CONSTRUCTION AND MAINTENANCE
The United Nations contracted E-J to maintain electrical, electronic, broadcasting and communications systems throughout the New York Headquarters. An engineering staff and a workforce of over 140 electricians and technicians were permanently on site. E-J budgeted all proposed projects and reviewed the design from an engineering standpoint before installation. We varied the size of our workforce to meet changing requirements. Our staff also worked on long term projects and the redesign of systems to improve efficiency and reduce costs. We brought Con-Edison energy saving/rebate programs to the facility and constantly discussed new technology (from lighting controls and premises distribution to simultaneous translation). We continuously deliver multi-faceted projects for the UN. Working in active occupied spaces while minimizing impacts to UN diplomatic and organizational operations.
Location: Flushing Meadow Corona Park Flushing , NY
Client: Turner Construction Co.
USTA NATIONAL TENNIS CENTER
The National Tennis Center is the home of the annual US Open Tennis Championship. This project was the expansion and redevelopment of a forty-two acre site with the new 23,000 seat Arthur Ashe Stadium as its centerpiece. Installation of all Low-Voltage Systems including Broadcast TV/Radio, Scoring, Internal Cable TV System, Internal Audio, Voice, and Computer Networking. This project was a turnkey project and included the cabling system as well as the active components. The cable plant consists of over 2.2 million feet (415 miles) of high performance cable with over 80,000 terminations. E-J also designed and implemented a fiber optic network for the entire campus on behalf of the USTA.
Expansion and redevelopment of the USTA National Tennis Center in Flushing Meadows Park, the home of the annual US Open Grand Slam Championship Tournament. The existing site is 17.3 acres and is being expanded by 24.9 acres consisting of a new 23,000 seat Arthur Ashe Stadium, fifteen site courts, nine new practice courts, a new food court and renovations to the existing stadium.
E-J’s scope included the installation of turnkey multi-media systems, covering network (CBS & International) broadcast, internal cable TV distribution, scoring systems and audio capabilities covering telephone, umpire, and scorekeeper announcements. Systems supplied include television head end equipment, remote fiber optic cameras, outdoor high capacity loudspeakers and all electronic equipment.
The broadcast system installed by E-J is used by CBS/USA-TV and all major foreign networks for full coverage of the US Open . The stadium also contains six TV studios, three interview rooms, thirty TV broadcast booths and ten radio broadcast booths. The stadium has full camera coverage with camera platforms. Camera boxes are each equipped with multiple custom-made Triax, Precision Video, Coax, and Audio Cables runback to the teleproduction area. This teleproduction area is linked via a fiber optic network back to a remote satellite up link site.
The site has four show courts with full broadcast capabilities. The show courts also have fixed cameras with a fiber optic link to the TV head end system in the stadium for broadcasters to view on air matches without need for a crew. It is also fed into the internal TV distribution.
INTERNAL TV DISTRIBUTION
The USTA campus contains a dedicated cable TV system. Its’ five miles of Broadband trunk cable & eighteen miles of TV drop cable feed over 1000 TV’s throughout the site with a variety of programming choices. This state of the art 750MHz system is capable of generating over 117 channels from a multitude of sources, including direct feeds from the many cameras placed throughout the stadium, as well as regular broadcast TV, financial news and a variety of movie choices.
The Audio system is comprised of many stand alone sub systems, which are linked together via a computer controlled digital audio matrix custom programmed by E-J. This 15,000 watt system is carried throughout the complex as a second audio program (SAP) distributed on the cable TV system.
In addition, the audio system generates the output for the speech reinforcement of the umpire and scorekeeper on Stadium Court and the show courts. Outdoor loudspeaker systems are used for this and are sized based on coverage area.
The audio system also distributes audio signals for broadcasters use. These signals are umpire, scorekeeper, ambient sound, and interview room feeds.
COMPUTERIZED SCORING SYSTEM (IDS)
All courts including Stadium Court are fed back to main scoring computer room in new stadium. Scoreboards are throughout campus. Scores and statistics are relayed to all scoreboards. The Information Display System (IDS) maintains all scores and statistics for all matches including those in progress on site and is updated in real time.
All courts (including stadium) are equipped with clocks, scoreboards and radar guns that tie into scoring system.
Throughout the site PCs tied in to systems can retrieve match statistics on current or past matches.
The scoring system is tied together on the USTA Fiber Optic Network and is the first permanent scoring system of its kind.
USTA FIBER OPTIC NETWORK
Five miles of Fiber Optic Cables tie the entire campus together supporting multiple applications.
E-J designed and implemented this Siecor fiber optic network to support systems including Video, Audio, scoring, point of sale, USTA Intranet and gateway to the internet.
The telephone cable plant, a certified Lucent/AT&T Systimax Structured Cabling System, is fully distributed to the entire campus. The new stadium houses the USTA’s upgraded Northern Telecom PBX system. The stadium will have four telephone closets per level. Riser cabling emanates from the PBX room. Telephone stations are run for back office, media rooms, private suites, broadcast booths and pay phones throughout stadium.
For the site, feeders are run from stadium PBX to hubs throughout site for distribution to field courts, outbuildings, pay phones, teleproduction area, and corporate hospitality areas. All site work is outside plant with power protection on all cable terminations.
This system is cabled to provide over 14,000 telephone lines in its current configuration. This telephone system will support many applications including analog voice (POTS), digital voice, ISDN, IEEE802.3 Ethernet, IEEE 802.5 Token Ring, and RS232D. E-J, a Lucent SCS VAR, has provided the USTA with a fifteen year performance warranty for this cabling plant.
Owner: Sempra Energy
Location: 58 Commerce Road Stamford , CT
Client: A.P. Construction
SEMPRA ENERGY TRADING
A 36,000 sq. foot state-of-the-art facility in which we worked with the architect to perform due diligence reports on various sites, assisted the architect and Construction Manager with conceptual budgets, to final design documentation. The trading floor consisted of 94 traders. Each trader location is serviced by twelve four pair UTP category 6 rated cables. The Communications Room is 2100 square feet which contains thirty eight cabinets, network control furniture, Turret PBX, PBX, incoming services and XLBET frames for horizontal cables, inter-rack cables, Turret and PBX tails and a fiber rack for inter-rack cabling. All cabinets contain fiber and copper patch panels. The facility has a raised floor, which contains cable tray for horizontal distribution.
Owner: Colgate Palmolive
Location: 300 Park Avenue New York , NY
Client: Colgate Palmolive
Ongoing electrical maintenance of all Colgate Palmolive office space on 18 floors, 605,000 sq. ft. at 300 Park Avenue. On-site maintenance staff increases to perform major renovations and lighting retrofits. Additional work included installing sub-meters on all panels.
Owner: Port Authority of NY & NJ
Location: 5 WTC New York , NY
Client: Port Authority of NY & NJ
WORLD TRADE CENTER SECURITY SYSTEM
E-J was Prime Contractor for 34 million-dollar Design/Build/Maintain project for the WTC Security System. The site consists of four buildings on a sixteen acre “footprint”, two major towers of 110 stories, rising to 1,350 feet with each floor consisting of about one acre in area. This design-build security project included: control access to sensitive building areas, access controls to interior building areas, centralize security monitoring and coordination, system redundancy using a Parking Access Control system, CCTV system, Door Access Control system, Intrusion Detection/Alarm system, lobby turnstiles & barriers, visitors desk stations, digital badging, door locking, intercoms, and duress alarms. E-J erected a primary Security Command Center and a backup Security Command Center, Master Computer system as well as Redundant Computer systems including a Communication Network utilizing 1,500,000 feet of fiber optic cable and a backup electrical power supply system. E-J was chosen on a negoitiated basis using technology, long term maintenance, management ability and price as a criteria.
As prime contractor, E-J had the engineer, general contractor and security integrator all working under its supervision.
Owner: Wein Malkin / Helmsley Spear
Client: Royal/ Enobil Partition/Durant
INTERNATIONAL TOY CENTER
E-J has a permanent satellite office at this Showroom Building/Landmark Building. We are in charge of the maintenance on all fifteen floors, the major International Toy Show every February with temporary set-ups for multiple vendors and the monitoring of the electrical system during Toy Trade Show. We also design/build jobs, do emergency on-call work, service calls and estimating, etc.
Owner: City of New York Parks Department
Location: Flushing Meadow Park Corona , NY
Client: City of New York Parks Department
Electrical maintenance of all electrical systems and scoreboards including Diamond Vision. Maintenance includes field electrical maintenance, audio-visual hook-ups with affiliated TV, radio, electronic signs, concession stands, lighting and new construction in the Stadium. Also completed five major projects in the Stadium.
E-J provides year round maintenance for the stadium including all labor, material and equipment. Maintenance includes the operation of all scoreboards, Diamond Vision, electronic signs and concession stands in the stadium.
We also provide maintenance to The NY Mets. We are responsible for all media hook-ups in and outside the stadium for radio, TV and cable.
We have just concluded the replacement of all the main feeders (42 sets of 4-1 million MCM cable underground) along with the entire replacement of (6) 4000 amp main switches. Installed new 350kW generator to new location and the completion of the replacement and re-engineering of new field lighting.
E-J has been renewed their award of multi-year contracts along with a high recommendation from stadium operations.
Owner: Port Authority Bus Terminal
Location: New York, NY
Client: VRH Construction Corporation
NY/NJ PORT AUTHORITY BUS TERMINAL
E-J Electric is a preferred contractor as a result of their workmanlike efforts and dependability. All work at the PABT has to be precisely coordinated with the facility so bus service and passenger comfort and safety is not impacted. E-J has been involved in a number of high profile projects beginning with the ADA Gate Modification Project. This two year facility-wide project included 106+ gates and has enabled the PABT to become ADA compliant. The Motor Stair Entrance Renovation on the main level was designed specifically to make passenger stairways safer and more efficient for all commuters departing and arriving through the installation of new lighting and the renovated fire alarms system. The renovation and new build-out of the tenant restrooms was designed to provide improved lavatory facilities for public access and transportation personnel. This project included lighting, power, HVAC, and control work. Our signature project has been the replacement chiller project. E-J’S medium voltage scope of work consisted of installing four new chillers and starters. The installation included 5kV feeders to the new 4th floor chiller plant. The 3rd floor plant was reconfigured which dictated a careful blending of new and old circuiting. Large additions to the base building fire alarm system, CCTV, and an extensive intricate control work was performed on the low voltage systems.
Location: 225 Fifth Avenue New York , NY
Client: Gift Building
Showroom building consisting of 12 floors with multiple tenants/vendors. The work consisted of diversified showroom lighting, maintaining dimming board system for the main lobby and the majority of building maintenance.
